NSN'd Silva 54/6400B Compass with FREE Compass Cover & Free Hardcover

Availability: In stock

Regular Price: $389.00

Special Price $329.00

Quick Overview

HURRY! Very Limited Stock


Probably the most resourceful compass in the world for artillery; target acquisition and command posts.


The Expedition 54 is a unique compass featuring both an optical precision sighting system and a SILVA 1-2-3 SYSTEM compass in the same unit, giving unbeatable precision and versatility in the field. Bearings can be taken with accuracy to within half a degree.

6400 mils on the graduation ring and 6400 mils and 360 degrees on the sighting scale.

With beta light i.e. will give continuous light up to 7.5 years.

WITH FREE;



Features



  • Accuracy± 0,5° (8.9 mils)

  • Altitude use5000m @-15 °C

  • Declination adjustmentNo

  • Graduation6400° / 360°

  • IlluminationBeta light - will give continuous light up to 7.5 years

  • Impact resistance30g in XYZ directions and free fall from 1.5 m height into gravel

  • Magnifying lensYes

  • MaterialAcrylic

  • Patented red/black N/S lines in capsuleYes

  • Resolution degrees / milsOuter ring: 2/50 Precision sighting scale: 1/20

  • ScalesBaseplate: 1:25k, 1:40k, 1:50k, mm, inch

  • Settling time from 90° angle to complete rest6 sec

  • Settling time from 90° angle within ± 3°4 sec

  • Sighting SystemPrismatic precision

  • Silicon friction feetYes

  • Size126 x 60 x 16 mm

  • Temperature operating range-40 to +60 °C

  • Type of compassSilva 1-2-3 System combined with a Lensatic precision sighting compass

  • UTM position plotting scales (Romer scales)1:25k, 1:40k, 1:50k

  • Water resistanceIP68 - (10 m)

  • Weight39g

  • NSN 6605-66-110-8985

  • Free Platatac DPC soft cover
